Male Connector

Male Connector

1400 INR/Piece

Product Details:

  • Material Stainless Steel
  • Size 3-25mm
  • Supply Ability : 1000 Piece Per Month
  • Click to view more
X

Price And Quantity

  • 1400 INR/Piece
  • 10 Piece

Product Specifications

  • Stainless Steel
  • 3-25mm

Trade Information

  • 1000 Piece Per Month
  • 2-3 Week
  • Corrugated boxes
  • Middle East, South America, North America, Central America
  • All India

Product Description

Technical Specification

Part No.

Tube O.D(T)

P (NPT)

EMin

h

H

F

G

I

L

in

mm

in

mm

in

mm

2AVMC-2
2AVMC-4N
2AVMC-6N
2AVMC-8N

1/8
1/8
1/8
1/8

3.17
3.17
3.17
3.17

1/8
1/4
3/8
1/2

2.3
2.3
2.3
2.3

7/16
9/16
11/16
7/8

11.11
14.28
17.46
22.22

7/16
7/16
7/16
7/16

11.11
11.11
11.11
11.11

12.7
12.7
12.7
12.7

15.2
15.2
15.2
15.2

23.9
29.0
29.2
35.6

30.5
35.6
35.8
42.2

3AVMC-2N
3AVMC-4N

3/16
3/16

4.76
4.76

1/8
1/4

3.0
3.0

7/16
9/16

11.11
14.28

1/2
1/2

12.70
12.70

13.7
13.7

16.0
16.0

24.7
29.7

31.2
36.3

4AVMC-2N
4AVMC-4N
4AVMC-6N
4AVMC-8N
4AVMC-12N

1/4
1/4
1/4
1/4
1/4

6.35
6.35
6.35
6.35
6.35

1/8
1/4
3/8
1/2
3/4

4.8
4.8
4.8
4.8
4.8

1/2
9/16
11/16
7/8
1-1/16

12.70
14.28
17.46
22.22
26.98

9/16
9/16
9/16
9/16
9/16

14.28
14.28
14.28
14.28
14.28

15.2
15.2
15.2
15.2
15.2

17.8
17.8
17.8
17.8
17.8

25.4
30.5
31.0
37.4
38.9

32.8
37.8
38.4
44.7
46.2

5AVMC-2N
5AVMC-4N
5AVMC-6N

5/16
5/16
5/16

7.93
7.93
7.93

1/8
1/4
3/8

4.8
6.4
6.4

9/16
9/16
11/16

14.28
14.28
17.46

5/8
5/8
5/8

15.87
15.87
15.87

16.3
16.3
16.3

18.5
18.5
18.5

26.7
31.3
31.8

34.0
38.6
39.1

6AVMC-2N
6AVMC-4N
6AVMC-6N
6AVMC-8N
6AVMC-12N

3/8
3/8
3/8
3/8
3/8

9.52
9.52
9.52
9.52
9.52

1/8
1/4
3/8
1/2
3/4

4.8
6.5
7.0
7.0
7.0

5/8
5/8
11/16
7/8
1-1/16

15.87
15.87
17.46
22.22
26.98

11/16
11/16
11/16
11/16
11/16

17.46
17.46
17.46
17.46
17.46

16.8
16.8
16.8
16.8
16.8

19.3
19.3
19.3
19.3
19.3

28.0
32.5
32.5
38.9
40.4

35.3
39.9
39.9
46.2
47.8

8AVMC-2N
8AVMC-4N
8AVMC-6N
8AVMC-8N
8AVMC-12N
8AVMC-16N

1/2
1/2
1/2
1/2
1/2
1/2

12.70
12.70
12.70
12.70
12.70
12.70

1/8
1/4
3/8
1/2
3/4
1

4.8
6.5
10.0
10.0
10.0
10.0

13/16
13/16
13/16
7/8
1-1/16
1-3/8

20.63
20.63
20.63
22.22
26.98
34.92

7/8
7/8
7/8
7/8
7/8
7/8

22.22
22.22
22.22
22.22
22.22
22.22

22.9
22.9
22.9
22.9
22.9
22.9

21.8
21.8
21.8
21.8
21.8
21.8

28.7
33.3
33.3
38.9
40.4
47.0

38.9
43.4
43.4
49.0
50.5
57.2

10AVMC-6N
10AVMC-8N
10AVMC-12N

5/8
5/8
5/8

15.87
15.87
15.87

3/8
1/2
3/4

10.0
12.0
12.0

15/16
15/16
1-1/16

23.81
23.81
26.98

1
1
1

25.40
25.40
25.40

24.4
24.4
24.4

21.8
21.8
21.8

34.0
38.9
40.4

44.2
49.0
50.5

12AVMC-8N
12AVMC12N
12AVMC-16N

3/4
3/4
3/4

19.05
19.05
19.05

1/2
3/4
1

12.0
16.0
16.0

1-1/16
1-1/16
1-3/8

26.98
26.98
34.92

1-1/8
1-1/8
1-1/8

28.57
28.57
28.57

24.4
24.4
24.4

21.8
21.8
21.8

40.4
40.0
47.0

50.5
50.5
57.2

14AVMC-12N
14AVMC-16N

7/8
7/8

22.22
22.22

3/4
1

16.0
18.0

1-3/16
1-3/8

30.16
34.92

1-1/4
1-1/4

31.75
31.75

25.9
25.9

21.8
21.8

40.4
47.0

50.5
57.2

16AVMC-8N
16AVMC-12N
16AVMC-16N

1
1
1

25.40
25.40
25.40

1/2
3/4
1

12.0
16.0
22.0

1-3/8
1-3/8
1-3/8

34.92
34.92
34.92

1-1/2
1-1/2
1-1/2

38.10
38.10
38.10

31.2
31.2
31.2

26.4
26.4
26.4

45.2
45.2
50.0

57.4
57.4
62.2

Part No.

Tube O.D.
T (mm)

p
(PT)

E
Min

h

H

F

G

I

L

M3AVMC-2R
M3AVMC-4R

3
3

1/8
1/4

2.3
2.3

11.1
14.3

11.1
11.1

12.9
12.9

15.3
15.3

23.1
29.0

29.7
35.6

M4AVMC-2R
M4AVMC-4R

4
4

1/8
1/4

2.3
2.3

11.1
14.3

12.7
12.7

13.7
13.7

16.1
16.1

24.6
29.7

31.2
36.3

M6AVMC-2R
M6AVMC-4R
M6AVMC-6R
4M6AVMC-8R

6
6
6
6

1/8
1/4
3/8
1/2

4.8
4.8
4.8
4.8

12.7
14.3
17.5
22.2

14.3
14.3
14.3
14.3

15.3
15.3
15.3
15.3

17.7
17.7
17.7
17.7

25.4
30.2
31.0
36.6

32.8
37.6
38.4
44.0

M8AVMC-2R
M8AVMC-4R
M8AVMC-6R
M8AVMC-8R

8
8
8
8

1/8
1/4
3/8
1/2

4.8
6.4
6.4
6.4

14.3
14.3
17.5
22.2

15.9
15.9
15.9
15.9

16.2
16.2
16.2
16.2

18.6
18.6
18.6
18.6

26.7
31.2
31.8
37.3

34.2
38.7
39.2
44.8

M10AVMC-2R
M10AVMC-4R
M10AVMC-6R
M10AVMC-8R

10
10
10
10

1/8
1/4
3/8
1/2

4.8
6.4
8.0
8.0

17.5
17.5
17.5
22.2

19.1
19.1
19.1
19.1

17.2
17.2
17.2
17.2

19.5
19.5
19.5
19.5

28.7
33.3
33.3
38.1

36.3
40.9
40.9
45.7

M12AVMC-4R
M12AVMC-6R
M12AVMC-8R
M12AVMC-12R

12
12
12
12

1/4
3/8
1/2
3/4

6.4
10.0
10.0
10.0

20.6
20.6
22.2
27.0

22.2
22.2
22.2
22.2

22.8
22.8
22.8
22.8

22.0
22.0
22.0
22.0

33.3
33.3
38.1
38.9

43.4
43.4
48.2
49.0

M15AVMC-8R

15

1/2

12.0

23.8

25.4

24.4

22.0

38.9

49.0

M16AVMC-4R
M16AVMC-6R
M16AVMC-8R
M16AVMC-12R

16
16
16
16

1/4
3/8
1/2
3/4

6.4
10.0
12.0
12.0

23.8
23.8
23.8
27.0

25.4
25.4
25.4
25.4

24.4
24.4
24.4
24.4

22.0
22.0
22.0
15.3

34.0
34.0
38.9
38.9

44.1
44.1
49.0
49.0

M18AVMC-8R
M18AVMC-12R

18
18

1/2
3/4

12.0
15.0

27.0
27.0

30.2
30.2

24.4
24.4

22.0
22.0

40.4
40.4

50.5
50.5

M20AVMC-8R
M20AVMC-1R

20
20

1/2
3/4

12.0
16.0

30.2
30.2

31.8
31.8

26.0
26.0

22.0
22.0

42.2
42.2

52.3
52.3

M22AVMC-12R
M22AVMC-16R

22
22

3/4
1

16.0
18.0

30.2
34.9

31.8
31.8

26.0
26.0

22.0
22.0

42.2
47.8

52.3
57.9

M25AVMC-12R
M25AVMC-16R

25
25

3/4
1

16.0
22.0

34.9
34.9

38.1
38.1

31.3
31.3

26.5
26.5

45.2
50.0

57.9
62.3


A. V. I. INTERNATIONAL
