Part No

Tube O.D
T

E
Min

h

H

F

G

I

L

in

mm

in

mm

in

mm

2AV U C

1/8

3.17

2.3

7/16

11.11

7/16

11.11

12.7

15.2

15.7

22.4

3AV U C

3/16

4.76

3.0

7/16

11.11

1/2

12.70

13.7

16.0

17.8

24.4

4AV U C

1/4

6.35

4.8

1/2

12.70

9/16

14.28

15.2

17.8

19.6

26.9

5AV U C

5/16

7.93

6.4

9/16

14.28

5/8

15.87

16.3

18.5

21.3

28.7

6AV U C

3/8

9.52

7.0

5/8

15.87

11/16

17.46

16.8

19.3

23.1

30.5

8AV U T C

1/2

12.70

10.0

13/16

20.63

7/8

22.22

22.9

21.8

25.9

36.1

10AV U C

5/8

15.87

12.0

1

25.40

1

25.40

24.4

21.8

28.7

38.9

12AV U C

3/4

19.05

16.0

1-1/16

26.98

1-1/8

28.57

24.4

21.8

29.7

39.9

14AV U C

7/8

22.22

18.0

1-1/4

31.75

1-1/4

31.75

25.9

21.8

34.5

44.7

16AV U C

1

25.40

22.0

1-3/8

34.92

1-1/2

38.10

31.2

26.4

36.8

49.0

Part No

Tube O.D.
Tmm

E
Min

h

H

F

G

I

L

M3AV U C

3

2.3

11.1

11.1

12.9

15.3

17.0

23.6

M4AV U C

4

2.3

11.1

12.7

13.7

16.1

18.8

25.4

M6AV U C

6

4.8

12.7

14.3

15.3

17.7

19.6

27.0

M8AV U C

8

6.4

14.3

15.9

16.2

18.6

21.3

28.8

M10AV U C

10

8.0

17.5

19.1

17.2

19.5

23.9

31.5

M12AV U C

12

10.0

20.6

22.2

22.8

22.0

25.9

36.0
